Features

➢ Adjustable AC frequency per your needs.
➢ PWM control technology enables fast and stable arc starting.
➢ Five welding processes: AC TIG; AC pulse TIG; DC TIG; DC pulse TIG; ARC.
➢ Cleaning zone width can be adjusted to meet high technological requirements.
➢ Adjustable slop up/down, Gas Pre-flow and Post-flow control for maximum shielding gas protection before and after the weld
➢ Pulsed function for Aluminium welding.
➢ 27/4T up and down slope application for welding with torch switch
➢ Excellent welding capability: aluminum, copper, carbon steel, stainless steel and
➢ Capable for different shapes welding, like butt-joint, corner joint, T-joint,lap-joint and cruciform joint
Catalog

https://www.ambitionweld.com/wp-content/uploads/2023/03/JTG400ACDC.pdf
PARAMETER UNIT acdc 400
Input Voltage V 380V±10%
Frequency Hz 50/60
Phase Three
ARC Starting Type HF
Open Circuit Voltage V 64
lnput Power Capacity kVA 8.7
Current Regulating Range A 10-400
Rise time Sec 0-10
Delay times Sec 1-10
Fall times Sec 0-10
Pre Gas Flow Sec 0-5
Duty Cycle at (40 °C) % 60
Efficiency % 85
Power factor cos 0.93
Degree of Protection Class IP21S
lnsulation Grade F
Weight kg 37
