Principle of laser cutting: it uses high-density laser beam passing through the laser head to focus the laser so that the metal can be melted rapidly, at the same time, with the help of the high-speed air flow coaxial with the beam, the molten material is blown away, so as to achieve the purpose of cutting.

Model: JFLC-1530EX , JFLC-2040EX & JFLC-2060EX

Laser Power: 1000W/1500W/2000W/3000W/4000W/6000W

Working area: 3000mm*1500mm/4000mm*2000mm/6000mm*2000mm

Features

➢ Fiber laser cutting machine advantages: fast cutting speed, high photoelectric conversion rate, up to 40%, thinner cutting seam, smaller thermal deformation. It has the advantages of low using cost, low power consumption and long service life up to 100,000 hours.
➢ Materials: stainless steel plate, carbon steel plate, aluminum alloy, brass plate, galvanized plate, nickel plate, manganese plate, titanium alloy and other metal plates.
➢ Applicable industry: mechanical and electrical equipment, mechanical sheet metal, chassis cabinet, stainless steel products, decoration, kitchen and bathroom, lamps, automobile accessories, glasses, advertising signs, metal furniture, elevator, electrical appliances, metal external processing, etc
➢ Heavy duty machine body: adopts 12mm steel plate integral welding structure, and the crossbeam is made of iron plate welding and casting. After annealing, the stress is completely eliminated before rough machining, and after rough machining, vibration aging treatment is carried out before finishing, so as to ensure the long-term stability of the bed without deformation.
➢ Using imported servo motor and precision transmission mechanism, cutting precision is high.
➢ The imported high flexible cable are used to ensure the stability of the machine.
➢ Professional software can be used to design various graphics or characters for instant processing, flexible processing, simple and convenient operation.
Feature/Model JFLC-1530EX JFLC-2040EX JFLC-2060EX
Working Area 1500mm*3000mm 2000*4000 mm 2000*6000 mm
X/ Y/ Z Axis 1525mm/3025mm/150mm 2025mm/4025mm/150mm 2025mm/6025mm/150mm
Structure Gantry Type Gantry Type Gantry Type
Table Surface Blade Type Blade Type Blade Type
Bed Type Exchangeable Exchangeable Exchangeable
Laser Power Source Raycus Raycus Raycus
Laser cutting Head Raytools BT 240S Raytools BT 240S Raytools BT 240S
Cooling System Water Cooling Water Cooling Water Cooling
Reducer Shimpo Shimpo Shimpo
Software Cypcut Cypcut Cypcut
Rack & Pinion YYC YYC YYC
Motor Fuji Servo motor Fuji Servo motor Fuji Servo motor
Laser Power 1Kw, 1.5Kw , 2 Kw , 3 Kw , 4 Kw ,6 Kw
Positioning Accuracy ±0.03mm/m ±0.03mm/m ±0.03mm/m
Repositioning Accuracy ±0.03mm ±0.03mm ±0.03mm
Max. Moving Speed 140m/min 140m/min 140m/min
Max. Acc. Speed 1.2G 1.2G 1.2G
Max. Loading Weight 700kg 1400kg 2000kg
Overall Dimensions (L*W*H) 4900×2250×1700mm 6015×3300×1700mm
