Hand-held fiber laser welding machine changes the traditional laser welding mode, and uses the hand-held laser welding gun tube to replace the previous fixed optical path, it has more flexibility to access the position which are very hard to weld and welding the parts fastly at any angle.
Lasers welding produce a beam of high intensity light which, when focused into a single spot, provide a concentrated heat source, allowing narrow deep welds and fast welding speeds. The process is frequently used in high volume applications such as in the automotive and medical industries. Laser welding is a non-contact process which requires access to the weld zone from only one side of the parts being welded.

Model: JLW-1000/JLW-1500/JLW-2000

Laser Power: 1000W/1500W/2000W

Applicable Industries:
Cabinet, kitchen and bathroom, stairs and elevators, shelves, ovens, stainless steel door, window guardrail, distribution box, stainless steel household and other industries complicated and irregular welding process.

Features
Technical Specification

Features	➢ The hand-held welding gun replaces the previous fixed optical path, which is more flexible and convenient, realizes long-distance laser welding, and overcomes the limitation of the travel space of the worktable. ➢ The hand-held welding head is light and flexible, easy to operate, and can meet the requirements of welding at various angles and positions. ➢ The heat affected area is small when welding, which would not lead to work deformation, blackening and trace problems on the back. ➢ The welding is deep and firm, the melting is sufficient. ➢ Simple operation, beautiful welding seam, fast welding speed and no consumables. ➢ Low power consumption and low use cost.

Features

➢ The hand-held welding gun replaces the previous fixed optical path, which is more flexible and convenient, realizes long-distance laser welding, and overcomes the limitation of the travel space of the worktable.
➢ The hand-held welding head is light and flexible, easy to operate, and can meet the requirements of welding at various angles and positions.
➢ The heat affected area is small when welding, which would not lead to work deformation, blackening and trace problems on the back.
➢ The welding is deep and firm, the melting is sufficient.
➢ Simple operation, beautiful welding seam, fast welding speed and no consumables.
➢ Low power consumption and low use cost.

Item Model	Model: JLW-1000/JLW-1500/JLW-2000
Laser power	1000W/1500W/2000W
laser source type	Fiber laser source
Mode	Continuation
Laser wavelength	1080nm
Output power stability	±2%
Red light power	10mw
Fiber output connector diameter	50um
Cooling way	Built-in water cooling
Laser Source	Max laser source/JPT laser source/Raycus laser source(China brand) IPG laser source(Germany brand)
Protective gas	Nitrogen or Argon
Spot diameter(optional)	1.0mm/1.5mm/2.0mm
Fiber wire cable(depends on laser source brand)	10 meters
Welding clearance requirement	≤0.5mm
Electricity demand	AC 380V
Power consumption	<5KW
Working environment temperature	10℃~40℃
Humidity	10%~90%
