JPUG-NM cuts various types of steel including channel, curved plate and angled steel members. Made of aluminum alloy, the JPUG-NM is lightweight and easy to use & control the cutting Modes.

Features

➢ A sturdy portable machine for straight line & circle cutting & slow profile by hand guiding.
➢ Machine runs on an aluminium track supplied 1.8 mtr lengths.
"Aluminum rail; makes accurate
straight cuts; extendable track
allows cutting of longer parts"
➢ Low cutting production cost.
➢ It is designed for heavy duty jobs.
JPUG-NM series cutting tips are recommended for best performance.
➢ It is operated by 1/12 H.P single phase motor.
➢ Magnetic effect in the roller shaft of gear box.
➢ Movement of gas cutting nozzle is directly linked with magnetic roller shaft which results in fine cutting of metal.
"Proper
rail selection ensures the highest precision Cutting."
Catalog

https://www.ambitionweld.com/wp-content/uploads/2023/03/JPUG-NM.pdf
PARAMETER UNIT JPUG-NM
Input voltage V 220 V + 15%
Frequency Hz 50/60
Phase Single
Welding cutting capacity mm upto 170
Nozzle Type NM
Inlet Gas Hose connection  ¼” BSP RH & LH
Horizontal movement of torch mm 80
Vertical movement of torch mm 60
Speed of cutting material mm/min 120-990
Straight cut mtr depends on rail (1.8 mtr)
Circle cut mm 75-1200
Bevel cut mm 45° , 125 mm thick
Weight Kg 9
Dimensions L*W*H mm 440*255*245
