Arc welding is the process of joining metal – steel in this case – using electricity.
arc welding is well-priced and affordable, and the process often requires less equipment in the work place , only welding electrode.
It’s less sensitive to paint, corrosion, and dirt at the welding point, saving time on pre-welding clean-up
Process of arc welding machine is easy to change rods for different metals

Features

➢ Machine is mounted on a four wheeled trolley type stand for easy moving anywhere.
➢ Welding Transformers available for Single Phase and Two Phase connection as required
➢ Available in both Air Cooled as well as Oil Cooled versions
➢ Stepless Variation in Current helps in adjusting suitable current for wide range of jobs
➢ Automatiic temperature protection system, fan cooling, high efficiency and safe
➢ welding in a dirty & dusty environmental Possible.
➢ Suitable for indoor as well as outdoor work
Catalog

https://www.ambitionweld.com/wp-content/uploads/2023/04/JRG-450.pdf
Model JRG-250 JRG-300 JRG-350 JRG-400 JRG-450 JRG-600
Input Supply V 220/440 220/440 220/440 220/440 220/440 220/440
Phase 1-2 1-2 1-2 1-2 1-2 2
Frequency (HZS) Hz 50/60 50 50 50 50 50
Welding Current Range A 50-250 60-300 60-350 60-400 60-450 60-600
Max. Open Circuit Volta.(O.C.V) V 50 60 60 60 80 80
Max. Continuous Welding Current at 60% Duty Cycle 250 300 350 400 450 600
Duty Cycle % 60 60 60 60 60 60
current control Stepless Stepless Stepless Stepless Stepless Stepless Stepless
Operating Type Single holder Single holder Single holder Single holder Single holder Single holder
cooling Fan Cool Fan Cool Fan Cool Fan Cool Fan Cool Fan Cool
insulation class F F F F F F
Welding Electrode Size Min. mm 2.5 2.5 2.5 2.5 2.5 2.5
Welding Electrode Size Max. mm 3.15 3.15 3.15 moderate 3.15 , 4 4 4 & 5
Approx Weight kg 70 85 100 110 120 140
